Description

Nightforce C530 8-32x 56mm Mil-R

About Nightforce C530 8-32x 56mm Mil-R:

Each Nightforce NXS Rifle Scope has an objective lens assembly that focuses light rays more precisely for exceptional image clarity and color accuracy. Nightforce scopes also feature multi-coated lenses and convenient target turrets. The new Hi-Speed adjustments provide twice as much adjustment per rotation than previous models. Nightforce NXS Rifle Scopes must pass vigorous tests before leaving the factory in North Central Idaho so you are assured of getting a scope of the highest possible quality. Waterproof, fogproof and shockproof. Covered by a limited lifetime warranty.

Waterproof, fogproof, shockproof

Nightforce does not recommend the usage of turn in style rotary/dovetail type ring and base designs, especially those equipped with windage adjustment. Nightforce recommends only Picatinny-style mounting systems.

Illuminated reticles use one Panasonic CR2032 or equivalent battery.

Illuminated reticles have a pull on, push off switch (at the end of the parallax turret assembly). Illumination intensity is controlled from a rheostat inside the battery compartment. The rheostat is turned with a small jeweler’s screwdriver.

Technical Information

• Adjustment Graduation: 1/10 MIL
• Reticle: Mil-R
• Tube Diameter: 30mm
• Adjustment Click Value: 1/4 MOA or 1/10 MIL
• Adjustment Type: Click
• Exposed Turrets: Yes
• Finger Adjustable Turrets: Yes
• Turrets Resettable to Zero: Yes
• Zero Stop: Yes
• Turret Height: Medium
• Fast Focus Eyepiece: No
• Lens Coating: Multi-coated, Mil-Spec abrasion resistant
• Warranty: Lifetime factory warranty
• Rings Included: No
• Sunshade Included: Yes
• Sunshade Length: 3″
• Lens Covers Included: Yes, bikini style
• Power Variability: Variable
• Min power: 8x
• Max power: 32x
• Reticle Construction: Glass-etched
• Illuminated Reticle: Yes
• Battery Type: CR2032 3V (1)
• Holdover reticle: No
• Reticle Focal Plane Location: 2nd
• Parallax Adjustment: Side Focus
• Finish: Matte
• Water/Fogproof: Yes
• Shockproof: Yes
• Airgun Rated: No
• Objective Bell Diameter: 65mm
• Ocular Bell Diameter: 43mm
• Eye Relief: 3.8″
• Max Internal Adjustment:
• Elevation: 65 MOA
• Windage: 45 MOA
• Exit Pupil Diameter: 7-1.8mm
• Weight: 34 oz
• Field of View at 100 Yards:
• 12.1′ @ 8x
• 3.1′ @ 32x
• Brands: Nightforce
• Obj. Aperture Diameter: 56mm
• Eye Relief: 3.8in
• Elev. Adjustment Range: 65 MOA
• Wind. Adjustment Range: 45 MOA

• Obj. Aperture Diameter: 56mm
• Eye Relief: 3.8in
• Elev. Adjustment Range: 65 MOA
• Wind. Adjustment Range: 45 MOA
